The reason for the high temperature of the motor in Jiangmen packaging equipment
What is the reason for the high temperature of the mechanical motor in Jiangmen packaging equipment? Excessive temperature rise during the operation of the vacuum packaging machine motor not only shortens its service life, but can also cause fires in severe cases. If the temperature rise of the electric motor is too high, please stop it immediately. Today, Shanghai Youte will talk about the reasons for excessive temperature rise:
The three-phase voltage is severely unbalanced. Check whether the stator winding is short circuited between phases or turns, and whether the stator winding is grounded.
2. Poor lubrication or jamming of the motor bearings of the vacuum packaging machine. Check if the temperature of the bearing box is higher than other parts to check if the grease is too low or too dry.
The malfunction of the ventilation system is caused by air duct blockage or dust accumulation on the radiator. Too thick grease can affect ventilation and heat dissipation.
4. The load is too large. If the mechanical belt is too tight and the shaft is not sensitive, it may cause the motor of the packaging equipment to overload for a long time. At this time, mechanical maintenance personnel should loosen the drive belt, disassemble and inspect the mechanical equipment, make the shaft flexible, and try to adjust the load to make the motor run under additional load.
5 harsh working environments. If the motor of the vacuum packaging machine is exposed to sunlight and the ambient temperature exceeds 40 ° C or the ventilation is poor, it will cause the motor temperature to rise. It can be covered with a simple pergola or blown away by a blower or fan to remove oil and dust from the air duct of the motor itself, and then the cooling conditions can be changed to either high or low power supply voltage. The motors of packaging equipment machinery and equipment operate within a range of -5 to 10% of changes in power supply voltage and can maintain additional capacity. If the power supply voltage exceeds 10% of the additional voltage, the magnetic flux density of the iron core will increase sharply, leading to iron loss and motor overheating. The detailed inspection method is to use a communication voltmeter to measure the bus voltage or the terminal voltage of the motor. If it is the voltage of the power grid, it should be reflected to the power supply department; If the voltage drop is too large, the conductor with a larger cross-sectional area should be replaced and the distance between the motor and the power supply should be shortened
Article source: Jiangmen Packaging Equipmenthttp://www.ciwsfu.cn/
-
